Description
Cox® Base Q 360 S/400-1, anthracite, H 360 mm
The Cox Base Q 360 S/400-1 waste system ensures optimum storage space organisation in the sink cabinet. It is compatible with the Quooker Pro3 & Cube boiling water reservoir. The model is designed for 600 mm wide cabinets with a front pull-out. The system has a removable waste container with a total volume of 22 litres. The practical housing cover closes the bin when it is pushed in. A rack for the water tank is also integrated and can be positioned either on the left or right side of the cabinet. A hose and cable management system is also included, so that everything has a fixed place. In addition, the installation frame makes it easy to replace the CO2 cylinder. With the help of an optional hose extension, the Quooker system can also be set up and connected in front of the cabinet. For easy and convenient operation, the waste collection system offers a full-extension pull-out as well as a soft pull-in with damping. The construction is designed for mounting on the cabinet side panel, the front panel as well as on the undershelf.



Suitable for the Quooker Cube cold water reservoir and the Pro3 boiling water reservoir.
For positioning in a sink base unit with a width of 600 mm.
simple, quick and flexible installation
positioning of the reservoirs on the left or on the right of the Cox® Base possible
— sturdy construction for mounting on the cabinet side wall, front panel and on the underside
— integrated hose and cable management
— simple replacement of the CO2 cylinder
— Quooker system can be set up and connected in front of the cabinet. The extension hoses required for this are listed below as accessories and can be ordered directly from Quooker.
— waste volume 22 litres
waste system with soft retraction and damping



Article type:
Waste collection system
CE marking on the product:
No
Cabinet width:
600 mm
Colour:
anthracite
Colour container lid:
anthracite
Colour guide:
anthracite
Colour total cover:
anthracite
Cover:
Yes
Depth:
470 mm
Design:
Front pull-out system
Form:
angular
Frame colour:
anthracite
Further:
integrated hose and cable management, positioning of the reservoirs on the left or on the right of the Cox® Base possible
Height:
500 mm
Lid type(s):
Complete lid
Material container:
plastic
Mounting/Fixing:
cabinet bottom, front panel, side wall
Number of containers:
1
Opening technology:
full pull-out
Rear wall height:
500 mm
Soft closing:
Yes
Total volume:
22 l
Volume/Content container:
22
Volume/content container 1:
22 l
Width:
600 mm

Accessories

Space-saving connector, white
Product number: 1051017
  • Drain pipe
Holder for CUBE filter
Product number: 8013367
  • Accessory

Spare parts

Frame, anthracite
Product number: 8013349
  • Accessory
  • angular
