STEEL flow Shutoff device/fire damper 150, galvanized steel
Product number:
4061040
- Exhaust air accessorie
- can be installed horizontally and vertically
- installation in the wall
Description
STEEL flow Shutoff device/fire damper 150, galvanized steel
The resistant COMPAIR® STEEL flow shut-off device serves as a fire damper in recirculation ducts of the fume extraction system. The damper is triggered at approximately 70 °C. It can be combined with round duct pipes of diameter 150 mm from the COMPAIR® STEEL flow series and is also compatible with plastic pipes. The fire protection element is particularly quiet and energy-efficient. It is made of galvanised steel with rustproof and non-combustible properties. The component offers a fire resistance duration of 90 minutes (K 90) and is classified according to DIN EN 18017-3. A DIBt certificate is also available. The fire protection can be installed either horizontally or vertically.
— K 90 classified according to DIN EN 18017-3
— triggered at approx. 70 °C
— DIBt certificate available
— can be installed horizontally and vertically
— connection to a plastic round pipe possible
— K 90 classified according to DIN EN 18017-3
— triggered at approx. 70 °C
— DIBt certificate available
— can be installed horizontally and vertically
— connection to a plastic round pipe possible
Article type:
Exhaust air accessorie
Brand:
STEEL flow
Colour:
grey
Connection diameter:
205 mm
Form:
round
Height:
205 mm
Length:
238 mm
Material:
galvanized steel
Mounting/Fixing:
can be installed horizontally and vertically, installation in the wall, plug-in system
Note:
connection to a plastic round pipe possible
Outer diameter:
150 mm
Standards:
K 90 classified according to DIN EN 18017-3
Surface/coating:
galvanised
System dimension:
150
Width:
205 mm
