MEC Driver LED 1-channel module radio/ZigBee, 12 V

Product number: 7061426

Accessory

Variant type

12 V

24 V

Prices will only be shown once logged in.

Description

MEC Driver LED 1-channel module radio/ZigBee, 12 V

The MEC Driver LED 1-channel module radio/ZigBee control unit is used to convert signals in kitchen lighting. It can be controlled by remote control or smart home application. Thanks to the integrated ZigBee Mesh, control is possible even without a bridge, since the components connect with each other. In addition, the driver offers a switchover between ambient lighting and individual lighting. It provides a channel with four LED outputs. The accessory is compatible with the LUMICA® LIC LED system. The compact module is made of plastic in white. It is available in different currents.

With a ZigBee 1-channel function module, up to four lights can be connected to one channel and controlled via remote control, ZigBee network or smart home (e.g. Alexa/Hue/Paulmann/Ikea).
When using the 1-channel module, one light group can be controlled separately.
Each 1-channel module can be individually assigned to the 4-channel remote control.
The module can be used together with other function modules on one converter. It can be deployed with single-colour and colour change lights.
— white
— 1-channel, 4 LED outputs
— max. 3 A per output, max. 5 A total
— control via remote control or smart home
— ZigBee Mesh even without a bridge (components connect to each other)
— simple teach-in
— switchable between emotion and single colour LEDs
— can be switched between colour change and single-colour lights

Article type:

Accessory

Colour:

white

Further:

ZigBee Mesh also without a bridge (components connect to each other), can be switched between emotion and single colour LEDs, control by remote control or smart home

Lighting system:

MEC LED system compatible

Lighting system voltage:

12 V

Output current:

max. 3 A per outlet, max. 5 A total

Variant type:

12 V

Downloads

Assembly

Data sheet
