Description
STEEL flow SF-VBS 150 pipe bend connector, galvanized steel
With the high-quality COMPAIR® STEEL flow SF-VBS 150 pipe bend connector, only two flat duct bends can be connected without flow losses. The connecting element is used in the kitchen system's exhaust air pipe routing and enables the safe installation of a change of direction. The ventilation fitting is made of galvanised, non-combustible sheet steel. It therefore meets high fire protection requirements. The curved connector is equipped with two profile seals for uncomplicated installation. It has a length of 90 mm and provides an outer diameter of 229 x 97 mm.



For connecting two flat duct bends. (Not suitable for connecting flat ducts)
— length 90 mm
— 2 SF profile linings pre-assembled



Article type:
Connecting element
Brand:
STEEL flow
Colour:
grey
Discontinued item:
No
Form:
angular
Height:
97 mm
Length:
90 mm
Material:
galvanized steel
Mounting/Fixing:
plug-in system
Note:
2 SF profile linings pre-assembled, Not suitable for connecting flat ducts
Outer diameter:
150 mm
Output drive:
angular
Surface/coating:
galvanised
Width:
229 mm
