Cornerstone Maxx fitting set, anthracite

Product number: 8037130

Swivelling fitting for corner cabinet
Cabinet width: for 900 mm or 1000 mm
Storage elements can be swivelled in and out independently

Colour

silver

anthracite

Prices will only be shown once logged in.

Description

Cornerstone Maxx fitting set, anthracite

Thoughtfully designed for everyday kitchen use: the Cornerstone Maxx corner cupboard swivel fitting as an efficient solution for corner base units. The set includes a standpipe, a pipe holder for the top and two swivel arms to hold the separately available Cornerstone Maxx shelves. To meet individual requirements, the base unit is available with a pull-out on the left or right. The straight pull-out swivel technology proves to be advantageous, as food supplies and other kitchen utensils can be easily reached. In addition, access to the neighbouring cupboard is not blocked. The length of the standpipe can be adjusted to suit the height of the cupboard. The pull-out system is mounted in the upper area and on the cupboard bottom.

Corner cupboard swivel fitting for accommodating shelves.

— for 900 mm cabinet width and 450 mm door width
— for 1000 mm cabinet width and 500 or 600 mm door width
— installation height 650–850 mm
— installation depth min. 490 mm
— telescopic
— swivels out to the right or left
— swivel technology that slides straight out, no obstruction of the adjacent cabinet

Set consisting of:
— standpipe
— 2 x swivel arm
— pipe fixture above

Please note:
Shelves need to be ordered separately!

Article type:

Swivelling fitting for corner cabinet

Cabinet width:

for 900 mm or 1000 mm

Colour:

anthracite

Direction swing:

left or right

For corner cabinets:

Yes

For door width:

450 - 600 mm

Installation_height_list:

650–850 mm

Installation depth:

min. 490 mm

Location:

base cabinet

Note:

Shelves need to be ordered separately, shelves that slide straight out: no obstruction of the adjacent cabinet

Number of floors:

Number of storage elements:

Opening technology:

swivel technology

Storage elements can be swivelled in and out independently:

Yes

Telescopic function:

Yes

Downloads

Assembly

Data sheet
